OpenAPI Parser Bundle Schemas

Bundle Specification

When OpenAPI or JSON Schema documents get massive or repetitive, the contents can be split across multiple documents (on the filesystem, URLs, in memory somewhere) and joined together $ref. These split up API descriptions can then be joined back together as one document, with $ref pointing to an internal location instead of an external location. This is called "bundling".

Now the sgcOpenAPI Parser supports bundling openAPI specifications. This is done automatically when importing a file.

Splitted OpenAPI Specification

openapi: 3.0.0
info:
  title: My API
  version: 1.0.0

paths:
  /things:
    get:
      responses:
        '200':
          description: 'OK'
          content:
            application/json:
              schema:
                properties:
                  data:
                    type: array
                    items:
                      $ref: './schemas/thing.yaml'

  /things/{id}:
    get:
      parameters:
        - name: id
          in: path
          required: true
          schema:
            type: string
            format: uuid
      responses:
        '200':
          description: 'OK'
          content:
            application/json:
              schema:
                $ref: './schemas/thing.yaml'

Bundled Specification

openapi: 3.0.0
info:
  title: My API
  version: 1.0.0
paths:
  /things:
    get:
      responses:
        '200':
          description: OK
          content:
            application/json:
              schema:
                properties:
                  data:
                    type: array
                    items:
                      $ref: '#/paths/~1things~1%7Bid%7D/get/responses/200/content/application~1json/schema'
  '/things/{id}':
    get:
      parameters:
        - name: id
          in: path
          required: true
          schema:
            type: string
            format: uuid
      responses:
        '200':
          description: OK
          content:
            application/json:
              schema:
                type: object
                properties:
                  id:
                    type: string
                    format: uuid
                  name:
                    type: string
                  type:
                    type: string
                    enum:
                      - type1
                      - type2

Output Parser Parameters

 The pascal file created from the openAPI specification now contains the parameters used to import the openAPI file. These parameters are created as comments in the top of the delphi file.

{ ***************************************************************************
  sgcOpenAPI component

  written by eSeGeCe
  copyright © 2024
  Email : This email address is being protected from spambots. You need JavaScript enabled to view it.
  Web : http://www.esegece.com

  Source: D:\Downloads\ICAR-ADE-1\url-schemes\registrationURLScheme.json
  Parsed At: 2024-10-02 10:12:18
  Options: [Generate Classes] [Enable Classes] [Documentation]
  Authentication: Token
  Method Name: OperationId
  Base URL: https://spec.openapi.com

  *************************************************************************** }

OnBeforeRequest event

This event is called before the HTTP request is called. Allows to customize the Parameter names, Headers, security... Find below an example how to replace the name of some parameters.

procedure OnBeforeRequestEvent(Sender: TObject; const aRequest: TsgcOpenAPIRequest);
var
  i: Integer;
  oParameter: TsgcOpenAPIParameter;
begin
  for i := 0 to aRequest.Parameters.Count - 1 do
  begin
    oParameter := aRequest.Parameters[i];
    if oParameter._Name = 'meta-modified-from' then
      oParameter._name := 'eventDateTime-from';
    if oParameter._Name = 'meta-modified-to' then
      oParameter._name := 'eventDateTime-to';
  end;
end;
