Indy Servers - Thread Model (1 / 3)

Alternatives to Indy Model

Instead of using 1 thread for every connection, there are alternatives like IOCP (for Windows) or EPOLL (for Linux) which make use of a pool of threads to handle the connections and use non-blocking sockets. This model is much more efficient when the number of concurrent connections is high and scales much better than the default Indy Thread Model.

IOCP (Windows)

I/O completion ports provide an efficient threading model for processing multiple asynchronous I/O requests on a multiprocessor system. When a process creates an I/O completion port, the system creates an associated queue object for threads whose sole purpose is to service these requests. Processes that handle many concurrent asynchronous I/O requests can do so more quickly and efficiently by using I/O completion ports in conjunction with a pre-allocated thread pool than by creating threads at the time they receive an I/O request.

IOCP Model uses non-blocking sockets, instead of using Select makes use of AcceptEx function and a pool of threads to handle the client connections.

To enable IOCP on sgcWebSockets Indy server just check the code below

oServer := TsgcWebSocketHTTPServer.Create(nil);
oServer.NotifyEvents := neNOSync;
oServer.IOHandlerOptions.IOHandlerType := iohIOCP;
oServer.Active := True;

A new WebSocket + HTTP Server will be created and a pool of threads will handle the connections, the number of threads used will depend on the number of cpu where the server is running.

EPOLL (Linux)

Epoll is a Linux kernel system call for a scalable I/O event notification mechanism, first introduced in version 2.5.44 of the Linux kernel. Its function is to monitor multiple file descriptors to see whether I/O is possible on any of them. It is meant to replace the older POSIX select and poll system calls, to achieve better performance in more demanding applications, where the number of watched file descriptors is large.

Check the following table comparing the performance for 100,000 monitoring operations:

So using epoll really is a lot faster once you have more than 10 or so file descriptors to monitor.

EPOLL Model uses non-blocking sockets, instead of using Select makes use of Accept async function and a pool of threads to handle the client connections.

To enable EPOLL on sgcWebSockets Indy server just check the code below

oServer := TsgcWebSocketHTTPServer.Create(nil);
oServer.NotifyEvents := neNOSync;
oServer.IOHandlerOptions.IOHandlerType := iohEPOLL;
oServer.Active := True;
